TTL / USB Impact Dot Matrix Printer For Queue Management System

TTL / USB Impact Dot Matrix Printer For Queue Management System
TTL / USB Impact Dot Matrix Printer For Queue Management System TTL / USB Impact Dot Matrix Printer For Queue Management System TTL / USB Impact Dot Matrix Printer For Queue Management System TTL / USB Impact Dot Matrix Printer For Queue Management System TTL / USB Impact Dot Matrix Printer For Queue Management System TTL / USB Impact Dot Matrix Printer For Queue Management System

Large Image :  TTL / USB Impact Dot Matrix Printer For Queue Management System

Product Details:
Place of Origin: China
Brand Name: MASUNG
Certification: CE; ROSH;UL
Model Number: MS-T380
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: cartons
Delivery Time: 5~8 woking days
Payment Terms: T/T/Paypal/Western union
Supply Ability: 2,000 units/monthly
Detailed Product Description
Printing Method:: Serial Impact Dot Matrix (9 Pins) Printing Speed:: 4.3 Lines/sec
Printing Direction:: Bi-directional Number Of Column: Approx 42 Columns
Home Position Sensor:: Photo Interrupter Font: 7*9 Matrix
High Light:

high speed dot matrix printer

,

small dot matrix printer

TTL / USB Impact Dot Matrix Printer For Queue Management System





Quick Detail:



 Support Windows/Android/Linux OS

 Paper jam prevention bezel

 Printer mechanism DP380

 Reliable auto cutter

 9 pins serial impact dot matrix

 Auto cutting (full/partial by adjustable)

 Black mark detection

 Utra big paper holder

 Paper near end detection

 Multiple detection sensors



Description:



MS-T380  is one of impact dot matrix printers which is used for kiosks, terminals,financial kiosk,coupon machine and more



Specification:



Mechanism

DP380

Printing method:

serial impact dot matrix (9 pins)

Printing speed:

4.3 lines/sec

 Printing direction:

bi-directional (logic seeking control)

Total no of dots:

210 dots

 Number of columns:

approx 42 columns

Font:

7*9 matrix

Number of pins:

9 pins

Character size(W*H):

1.25*3.12mm(7*9 dots)/1.25*2.42mm(7*7 dots)

Line spacing:

minimum 0.176mm (1/144 inch)

Character pitch:

1.59mm

Home position sensor:

photo interrupter

Paper end sensor:

photo interrupter

Stepping motor voltage:

DC 24V±5%

Copy capability:

original+1 copy

Paper width:

76mm ( normal paper)

Ink ribbon cartridge:

two colors( red and black), single color(black)

Paper feeding speed:

34 lines/sec

Weight:

2.14 kg

External dimension:

349.44*166.66*153.6 mm

Reliability: mechanism:

MCBF 5.0 million lines/ head: 100 million characters

Controlling board



Font:

7*9

Interface:

parallel; RS-232; USB

Command set:

ESC/POS

CPU:

72 MHz

SRAM:

64k bytes

NV Flash

2 M bytes

Driver:

windows7/xp/win8/Android OS

Total weight

1.15 kg

Accessories:

paper near end sensor, paper presenter unit, paper bezel, power supply unit; auto cutter; cable





Application:



Self-service terminal; ticket vendor; parking system; coupon machine; healthcare equipments, bill payment machine, inquiry machine, financial kiosk and more





Competitive Advantage:



Multiple diversification

Customization service offer

Product performance

Support Windows/Andriod/Linux

NV logo download support

Compatible with ESC/POS commands set

Have an original+1 copy

Small order accepted

Buyer label offer

Prompt delivery
