| High Light: | bus bar insulation tube,heat shrink,heat shrink tube |
||
|---|---|---|---|
| S1-10 Flame Retardant Bus Bar Insulation Heat Shrink Tube | ||||
| Features | ||||
| Medium wall cross-linked polyolefin | Operating temperature: -40~105 ℃ | |||
| Flame retardant | Shrink temperature: 125 ℃ | |||
| Bus bar insulation and protection | Shrink ratio: 2.5:1 | |||
| Reduces bus bar clearance requirement | Voltage class: 6~24KV | |||
| RoHS compliant | ||||
| Protects against short circuit and electrical leakage caused by small animals | ||||
| Dimensions | ||||
| Reference | As supplied(mm) | After recovered(mm) | Standard length | |
| UPM S1-10 | ID min. | ID max. | WT nom. | m/spool |
| 25/10 | 25 | 10 | 2.50 | 25 |
| 30/12 | 30 | 12 | 2.65 | 20 or 25 |
| 40/16 | 40 | 16 | 2.65 | 20 or 25 |
| 50/20 | 50 | 20 | 2.65 | 20 or 25 |
| 65/25 | 65 | 25 | 2.85 | 20 or 25 |
| 75/30 | 75 | 30 | 2.85 | 20 or 25 |
| 85/35 | 85 | 35 | 2.85 | 20 or 25 |
| 100/40 | 100 | 40 | 2.85 | 20 or 25 |
| 120/50 | 120 | 50 | 2.85 | 20 or 25 |
| 150/60 | 150 | 60 | 2.90 | 20 or 25 |
| 175/75 | 175 | 75 | 2.90 | 20 or 25 |
| Product selection | ||||
| Bus bar size (mm) | Single layer bus bar | Two layers bus bar | ||
| 20×3,25×3 | Φ25/10 | Φ30/12 | ||
| 30×3,30×4 | Φ30/12 | Φ40/16 | ||
| 30×10,40×4 | Φ40/16 | Φ50/20 | ||
| 40×10,50×5,50×6 | Φ50/20 | Φ65/25 (Φ75/30) | ||
| 50×8,50×10,60×6,60×8 | Φ65/25 (Φ75/30) | Φ75/30(Φ85/35) | ||
| 60×10,80×6,80×8,80×10 | Φ75/30(Φ85/35) | Φ100/40(Φ120/50) | ||
| 100×8,100×10,100×12 | Φ100/40(Φ120/50) | Φ120/50 | ||
| 100×15,120×10,120×12,120×15 | Φ120/50 | Φ150/60 | ||
| 150×12,150×15 | Φ150/60 | Φ175/75 | ||
| ID=Internal Diameter | WT=wall thickness | |||
| Typical application | ||||
| Suitable for insulation and protection of bus bar against accidental flashover up to 24 KV | ||||
| Ideal for using in switchgears cabinets where space is limited and air spacing between bus | ||||
| bars need to be kept at minimal | ||||
| Ordering | ||||
| Standard color : Red | ||||
| Standard packaging on spools. | ||||
| Please specify specification,quantity when ordering | ||||
| Cross reference | ||||
| Sumitomo: IRRAX sleeve SBI 300 | ||||
