Highlight: | CNC Router Engraver Machine,CNC Wood Engraving Machine |
---|
Feature:
¤ Bluetooth communication: Can be controlled by computer, smart mobile, laptop with Bluetooth.
¤ With external design memory (D card).
¤ Blue backlight big LCD: 4.2’’LCD, 128 segment digital display.
¤ Working area: CB730 with cutting width 700mm, CB1300 with cutting width 1270mm.
¤ High-precision roller stick.
¤ High quality buttons: Good hand feeling, durable, blue backlight.
¤ With laser point, can do contour cutting.
¤ Fashion white & metallic silver appearance.
¤ Main board and Driver board are both in the right cover, Convenient to maintain and replace.
¤ Low noise, Fan stops operating in stand by mode.
Specification:
Model |
ST730B |
ST1300B |
Media way |
M bracket or Stand |
Floor Stand |
Main board |
Cortex-M3 CPU , High-speed 32 bit processor |
|
Control Panel |
Highlight patterned LCD ,friendly operating keypad |
|
Drive |
Double high torsional force motor, micro-step driver |
|
Position |
Limit edge system, any origin setting |
|
Max paper feed width |
730mm |
1300mm |
Max cutting width |
700mm |
1270mm |
Max cutting speed |
600mm/s |
|
Max cutting length |
20000mm |
|
Max cutting thickness |
1.0mm |
|
Cutting pressure |
0-600g(digital adjustment) |
|
Mechanical precision |
0.05mm |
|
Repeatable precision |
≤0.1mm/twice(On 1000×1000mm square) |
|
Blade |
Carbide blade |
|
Pen |
All types diameter 11. 4mm plotter pen |
|
Command |
Compatible DM/PL,HP/GL |
|
Interface |
Blue tooth/USB Port/Serial Port/D Card |
|
Power supply |
INPUT AC110V±10% 1.0A 60Hz,AC220V±10% 0.5A 50Hz |
|
Power Consumption |
<100W |
<120W |
Working environment |
Temperature: 5℃~ 35℃, Relative Humidity: 30% ~70% |
|
External size |
1045×300×330mm3 |
1595×300×415mm3 |
Gross weight |
16kg |
29kg |
