Halogen free heavy wall heat shrinable tube with / without adhesive shrink ratio 3:1 for electrical wires insulation

Halogen free heavy wall heat shrinable tube with / without adhesive shrink ratio 3:1 for electrical wires insulation
Halogen free heavy wall heat shrinable tube with / without adhesive shrink ratio 3:1 for electrical wires insulation Halogen free heavy wall heat shrinable tube with / without adhesive shrink ratio 3:1 for electrical wires insulation Halogen free heavy wall heat shrinable tube with / without adhesive shrink ratio 3:1 for electrical wires insulation Halogen free heavy wall heat shrinable tube with / without adhesive shrink ratio 3:1 for electrical wires insulation

Large Image :  Halogen free heavy wall heat shrinable tube with / without adhesive shrink ratio 3:1 for electrical wires insulation

Product Details:
Place of Origin: China
Brand Name: Sunbow
Certification: UL no E360625,RoHS/REACH
Model Number: SB-SBRSW&SB-RSFRW
Payment & Shipping Terms:
Minimum Order Quantity: 500M
Price: USD0.09-16.4 per meter
Packaging Details: packing by rolls,50-200m/roll
Payment Terms: Western Union, T/T,paypal
Supply Ability: 9,000,000 meters per month
Detailed Product Description
Characteristic: Flexible, Flame Retardant, Eco-friendly, Quick Shrink, Bright Color Stand, Stable Performance Working Temperature: -45ºC ~ 125ºC
Shrink Ratio: 3:1 Shrink Temperature: 70ºC ~ 120ºC
Color: Black,white,red,blue,green... Size: Inner Diameter 10-85mm
High Light:

heat shrink tube

,

adhesive lined heat shrink tubing

Halogen free heavy wall heat shrinable tube with / without adhesive shrink ratio 3:1 for electrical wires insulation



Advantage:
1. Great production capability as high as 9,000,000 meters/month
2. Competitive price with quality products
3. Whole color UL certificated with inner diameter 10-85mm

Structure
Heavy wall heat shrinkable tube is manufactured by co-extrusion polyolefin and environment friendly hot-melt adhesive. It is designed to provide both insulation and sealing for protected articles. Both adhesive –lined and without adhesive are available.

Usage:
It has heavy wall, semi-rigid, sealing, insulation, damp proof performances. It is mainly used in electrons, electricity, telecommunications, automobile, shipping, aerospace manufacturing etc.

Characteristics:

  1. Shrink ratio: 3:1
  2. Shrink temperature: 70ºC ~ 125ºC
  3. Heavy wall, semi-rigid, insulated, excellent sealing performance

Dimension:


1) Flame Retardant Heavy Wall Heat Shrinkable Tube with Adhesive Lined

Inner Diameter
(mm)

As Supplied (mm)
ID

After Recovery(mm)

Standard Package (m/pc)

ID

Outer Layer Thickness

Adhesive Thickness

Whole Wall Thickness

9/3

≥9

≤3

2.0±0.20

0.35±0.10

2.30±0.25

1.22

13/4

≥13

≤4

2.4±0.20

0.35±0.10

2.75±0.25

1.22

20/6

≥20

≤6

2.5±0.20

0.40±0.10

2.90±0.25

1.22

28/9

≥28

≤9

2.5±0.20

0.40±0.10

2.90±0.25

1.22

33/10.2

≥33

≤10.2

3.2±0.20

0.40±0.10

3.60±0.25

1.22

38.1/12

≥38.1

≤12

3.4±0.20

0.60±0.15

4.00±0.30

1.22

43.2/12

≥43.2

≤12

4.3±0.20

0.70±0.20

5.00±0.35

1.22

51/16

≥51

≤16

4.3±0.20

0.70±0.20

5.00±0.35

1.22

70/21

≥70

≤21

4.3±0.20

0.70±0.20

5.00±0.35

1.22

85/25

≥85

≤25

4.3±0.20

0.70±0.20

5.00±0.35

1.22

105/30

≥105

≤30

4.3±0.20

0.80±0.25

5.10±0.35

1.22

120/39

≥120

≤39

4.3±0.20

0.80±0.25

5.10±0.35

1.22

140/42

≥140

≤42

4.3±0.20

0.80±0.25

5.10±0.35

1.22



2) Flame Retardant Heavy Wall Heat Shrinkable Tube without Adhesive Lined

Inner Diameter
(mm)

As supplied (mm)
ID

After Recovery(mm)

Standard Package  (m/pc)

ID

Whole Wall Thickness

9/3

≥9

≤3

2.30±0.25

1.22

13/4

≥13

≤4

2.75±0.25

1.22

20/6

≥20

≤6

2.90±0.25

1.22

28/9

≥28

≤9

2.90±0.25

1.22

33/10.2

≥33

≤10.2

3.60±0.25

1.22

38.1/12

≥38.1

≤12

4.00±0.30

1.22

43.2/12.7

≥43.2

≤12

5.00±0.35

1.22

51/16

≥51

≤16

5.00±0.35

1.22

70/21

≥70

≤21

5.00±0.35

1.22

85/25

≥85

≤25

5.00±0.35

1.22

105/30

≥105

≤30

5.10±0.35

1.22

120/39

≥120

≤39

5.10±0.35

1.22

140/42

≥140

≤42

5.10±0.35

1.22


Color:Standard is black,other colors available upon request


Company information



      Our main products include various fiberglass sleeving, silicone tube (especially the platinum cured silicone tube), PTFE tube, PVC tube, Heat shrinkable tube and so on.

      All our products have obtained theUL and CSA certificates (Cert No: E333178 --UZIQ2, VW-1 & E333177--UZFT2/8,200C, 600V).Also all our products are in conformance with the European RoHS requirements. Furthermore, based on European new requirements, we re-apply and obtained German PFOA and PFOS certificates and European REACH reportshowing that our products do not contain 73 high-risk substances. In Sep.2009, we successfully passed ISO9001:2008international quality management system certification, nowISO14001system is also pushing.
